Fmac Filtre Schurter FMAC 0954-H110

Fmac Filtre Schurter  FMAC 0954-H110

FMAC INPUT FILTER 3-PHASE 110A

Technical Data
Rated Current 6 – 1100 A @ Ta 40 °C
Rated Voltage 480 – 520 VAC, 50/60 Hz
Approval for 6 – 1100 A @ Ta 40 °C / 520 VAC; 50 Hz
Leakage Current industrial < 5 mA (440 V / 50 Hz)
Dielectric Strength for 480 VAC 2.25 kVDC between
3 kVDC between L-PE
Dielectric Strength for 520 VAC 2.25 between L-L
4 between L-PE
Test voltage (2 sec)
Number of Filter Stages 1
Weight 0.9 – 47 kg
Material: Housing Metal
Sealing Compound UL 94V-0
Mounting Screw-on mounting on chassis from
top
Terminal Screw Clamp
Operating Temperature [°C] -25 °C to 100 °C
Climatic Category 25/100/21 acc. to IEC 60068-1
Degree of Protection IP 20 acc. to IEC 60529
Protection Class Suitable for appliances with protection
class I acc. to IEC 61140
MTBF > 200’000 h acc. to MIL-HB-217 F
