Wenglor CP70QXVT80
Açıklama
Wenglor CP70QXVT80 Rekleftif Sensör-Refrektörlü Sensör
Optical Data
| Range | 660 mm |
| Adjustable Range | 60…660 mm |
| Switching Hysteresis | < 1 % |
| Light Source | Laser (red) |
| Wave Length | 655 nm |
| Service Life (T = +25 °C) | 100000 h |
| Laser Class (EN 60825-1) | 2 |
| Max. Ambient Light | 10000 Lux |
| Spot Diameter | see Table 1 |
Electrical Data
| Supply Voltage | 10…30 V DC |
| Current Consumption (Ub = 24 V) | < 50 mA |
| Switching Frequency | 250 Hz |
| Response Time | < 2 ms |
| On-/Off-Delay (RS-232) | 0…1 s |
| Temperature Drift | < 50 µm/K |
| Temperature Range | -25…60 °C |
| Switching Outputs | 2 |
| Switching Output Voltage Drop | < 1,5 V |
| Switching Output/Switching Current | 200 mA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Teach Mode | HT, VT, TP |
| Baud Rate | 38400 Bd |
| Protection Class | III |
| FDA Accession Number | 0820587-000 |
Mechanical Data
| Setting Method | Teach-In |
| Housing Material | Plastic |
| Degree of Protection | IP67 |
| Connection | M12 × 1; 8-pin |
