Endüktif Sensör Pepperl Fuchs NXN8-12GM50-E2-V1
Sensör
Yakınlık Sensörü
Proximity Sensor
Endüktif Proximity Sensör
Inductive Proximity Sensor
Pepperl Fuchs
Pepperl Fuchs Sensör
Pepperl Fuchs Proximity Sensor
Pepperl Fuchs Yakınlık Sensörü
Pepperl Fuchs Endüktif Proximity Sensör
Pepperl Fuchs Inductive Proximity Sensor
Pepperl Fuchs NXN8-12GM50-E2-V1
Pepperl NXN8-12GM50-E2-V1
NXN8-12GM50-E2-V1
Açıklama
Pepperl Fuchs NXN8-12GM50-E2-V1 Endüktif Sensör
Pepperl NXN8-12GM50-E2-V1 Inductive Sensor
Yaklaşım Sensörü Pepperl Fuchs NXN8-12GM50-E2-V1
Pepperl Fuchs NXN8-12GM50-E2-V1 Yakınlık Sensörü
Inductive Sensor NXN8-12GM50-E2-V1 Pepperl-Fuchs
Endüktif Sensör NXN8-12GM50-E2-V1 Pepperl-Fuchs
Teknik veriler NXN8-12GM50-E2-V1
| General specifications | |
| Switching function | Normally open (NO) |
| Output type | PNP |
| Rated operating distance | 8 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 … 6.48 mm ( -25 … 70 °C (-13 … 158 °F) ) 0 … 6.08 mm ( -40 … -25 °C (-40 … -13 °F) ) |
| Reduction factor rAl | 0.39 |
| Reduction factor rCu | 0.3 |
| Reduction factor r304 | 0.7 |
| Reduction factor rBrass | 0.45 |
| Output type | 3-wire |
| Nominal ratings | |
| Operating voltage | 10 … 30 V |
| Switching frequency | 0 … 450 Hz |
| Hysteresis | typ. 5% |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Voltage drop | ≤ 3 V |
| Operating current | 0 … 100 mA |
| No-load supply current | ≤ 16 mA |
| Switching state indicator | Multihole-LED, yellow |
| Ambient conditions | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) |
| Mechanical specifications | |
| Connection type | Connector M12 x 1 , 4-pin |
| Housing material | brass, nickel-plated |
| Sensing face | PBT |
| Housing diameter | 12 mm |
| Degree of protection | IP67 |
| General information | |
| Scope of delivery | 2 hex nuts included |
