Diyaframlı Pompa Graco Husky 1040

Graco Husky 1040 Diyaframlı Pompa

Air-Operated Diaphragm Pumps Graco Husky

VİDEO

Technical Specifications

Maximum fluid working pressure . . . . 120 psi (8.4 bar, 0.84 MPa)
Maximum free flow delivery* . .  40 gpm (151 lpm)
Maximum pump speed . . . . . . . . . . . . .267 cpm
Displacement per cycle** . . . . . . . . . . .0.15 gallon (0.57 liter)
Maximum suction lift (D72888) . . . . . .19 ft (5.8 m) dry
Maximum size pumpable solids . . . . . .0.13 in (3.2 mm)
Maximum operating temperature***
Teflon . . . 220°F (104.4°C)
Santoprene . . . 180°F (82.2°C)
Buna-N . . . .180°F (82.2°C)
Hytrel  . . . 150°F (65.5°C)
Viton . . . 250°F (121.1°C)
Geolast . . .  150°F (65.5°C)
Typical sound level at 70 psi air
(4.9 bar, 0.49 MPa) air @ 50 cpm . . . .76 dBa
Maximum air consumption . . . . . .60 scfm (1.7 m3/min)
Air pressure operating range . . . . 20 to 120 psi
(1.4 to 8.4 bar, 0.14 to 0.84 MPa)
Air inlet size . . . . . 1/2 npt(f)
Fluid inlet & outlet size . . .  1 in (25.4 mm) ANSI-flange
Weight
Acetal  . . . ..22 lb (10 kg)
Polypropylene . . . . . .19 lb (8.6 kg)
Polypropylene with Stainless Steel center section . . . . .30.9 lb (14 kg)
Kynar . . . 25 lb (11.3 kg)
Kynar with Stainless Steel center section . . . . . 36.9 lb (16.7 kg)
Instruction manual  . . .308443
